Submersible Pumps for 8″ deep wells or larger
Features
- 8″: VSC 144 – 132 – 156
- Cast Stainless Steel impellers and diffusers for high corrosion and abrasion resistance
- Robust, compact and reliable design
- Built-in check valve to protect the pump against water hammer
- The hydraulic design is such to enhance the overall efficiency thus reducing energy consumption and making the pumping systems more cost effective
Specification
- Flow:
- 8″: up to 144 m³/h at 50 Hz
- Head:
- 8″: up to 578 m at 50 Hz
- Maximum allowable amount of sand: 100 g/m³
- Water temperature: from -5 °C to +60 °C
- Rotation: counter clockwise when looking into the discharge
- Operation in vertical or horizontal position
- The hydraulic characteristics are guaranteed, according to ISO standard 9906:2012, grade 3B
Options
- YΔ version with second cable guard
- 316 SS & Duplex version
- Discharge:
- 8″: Rp5″
- 10″: counter flange (Rp6″ as of Q4/2018)
- 10″ counter flange (order no. 14262101)
- Other flows
